| RIVET
DIAMETER |
GRIP RANGE
(Inches) |
GRIP RANG
E(MM) |
RIVET CODES |
TYPICAL
SHELL LENGTH (L)
MM |
TYPICAL
RIVET CLEARANCE
(XX) MM |
| 73 STS/T |
72 STS/T |
NO.3
3/32”
2.4mm
|
Up to 1/16
1/16-1/8
1/8-3/16
3/16-1/4
1/4 -3/8
|
Up to 1.6
1.7-3.2
3.3-4.8
4.9-6.4
6.5-9.5
|
-
-
-
-
-
|
-
-
-
-
-
|
4.70
6.30
7.90
9.60
12.70
|
6.20
7.80
9.40
11.10
14.20 |
NO.4
1/8”
3.2mm |
Up to 1/16
1/16-1/8
1/8-3/16
3/16-1/4
1/4 -5/16
5/16-3/8
3/8-4/9
4/9-1/2
1/2-4/7
4/7-5/8
5/8-3/4
|
Up to 1.6
1.7-3.2
3.3-4.8
4.9-6.4
6.5-7.9
8.0-9.5
9.6-11.1
11.2-12.7
12.8-14.3
14.4-15.9
16.0-19.0
|
4-1
4-2
4-3
4-4
4-5
4-6
-
-
-
-
-
|
4-1
4-2
4-3
4-4
4-5
4-6
-
-
-
-
-
|
5.30
7.00
8.60
10.10
11.70
13.60
15.30
17.00
18.70
20.40
23.80
|
8.30
10.00
11.60
13.10
14.70
16.60
18.30
20.00
21.70
23.40
26.80
|
NO.5
5/32”
4.0mm |
Up to 1/16
1/16-1/8
1/8-3/16
3/16-1/4
1/4 -5/16
5/16-3/8
3/8-4/9
4/9-1/2
1/2-4/7
4/7-5/8 |
Up to 1.6
1.7-3.2
3.3-4.8
4.9-6.4
6.5-7.9
8.0-9.5
9.6-11.1
11.2-12.7
12.8-14.3
14.4-15.9 |
5-1
5-2
5-3
5-4
5-5
5-6
5-7
5-8
-
-
|
5-1
5-2
5-3
5-4
5-5
5-6
5-7
5-8
-
-
|
6.00
7.60
9.20
10.70
12.30
13.90
15.80
17.60
19.30
21.00 |
9.50
11.10
12.70
14.20
15.80
17.40
19.30
21.10
22.80
24.50
|
NO.6
3/16”
4.8mm |
Up to 1/16
1/16-1/8
1/8-3/16
3/16-1/4
1/4 -5/16
5/16-3/8
3/8-4/9
4/9-1/2
1/2-4/7
4/7-5/8
5/8-3/4
3/4- 7/8
7/8-1
1- 1 3/8 |
Up to 1.6
1.7-3.2
3.3-4.8
4.9-6.4
6.5-7.9
8.0-9.5
9.6-11.1
11.2-12.7
12.8-14.3
14.4-15.9
16.0- 19.0
19.1-22.2
22.3-25.4
25.5-28.5 |
6-1
6-2
6-3
6-4
6-5
6-6
6-7
6-8
-
-
-
-
-
-
|
6-1
6-2
6-3
6-4
6-5
6-6
6-7
6-8
-
-
-
-
-
-
|
6.60
8.30
9.80
11.40
13.00
14.50
16.20
17.70
19.60
21.60
24.80
28.20
31.50
|
10.60
12.30
13.80
15.40
17.00
18.50
20.20
21.70
23.60
25.60
28.80
32.20
35.50
|
NO.8
1/4”
6.4mm
|
1/16-1/8
3/16-1/4
5/16-3/8
4/9-1/2
4/7-5/8
5/8-3/4
3/4- 7/8
7/8-1 |
1.7-3.2
3.3-4.8
4.9-6.4
6.5-7.9
8.0-9.5
9.6-11.1
11.2-12.7
12.8-14.3
|
-
-
-
-
-
-
-
- |
-
-
-
-
-
-
-
- |
9.50
12.70
15.90
19.10
22.20
25.40
28.60
31.80
|
13.50
16.70
19.90
23.10
26.20
29.40
32.60
35.80
|
